Z-Axis Heavy Duty Type
Features
- Chinese /English handheld LCD screen operation, convenient programming and simple operation.
- With continuous interpolation of points, lines, surfaces, arcs and irregular curves, it can realize any 3D non-planar trajectory path dispensing.
- Excellent teaching function, support array, graphical browsing, three-dimensional ellipse, common graphics library insertion, group editing and other advanced functions.
- Large-capacity 2G high-speed Mini SD file storage, which can store 999 dispensing program files.
- The glue volume, glue speed, glue dispensing and glue stop time can all be parameterized.
Specifications
| Model | LT-E380S |
|---|---|
|
Effective Working Range
X/Y/Z |
380 / 380 / 100 mm |
|
Maximum Payload X/Y/Z |
20 / 20 / 15 kg |
|
Maximum Movement Speed XY/Z |
X / Y : 800 , Z : 200 mm/sec |
|
Repeat Accuracy X/Y/Z |
± 0.025 mm |
|
Transport System X/Y/Z |
Servo Motor + Lead Screw |
|
Dispenser |
100TD Dispenser |
|
Data Storage |
999 setup programs (each program with 65535 points) |
|
Operating System |
LCD, Teaching Pendant |
|
Dispensing Pattern |
Spot to spot, Continuous, Arc 3 dimensional |
|
I/O Signal |
Standard 1 Input, 4 Outputs, expandable to 10 Inputs, 10 Outputs |
|
Input Power |
AC 220 V , 50 / 60Hz |
|
Working Environment |
Temperature 0~40°C, Humidity 20~85% no condensation |
|
Dimensions (W x D x H) |
657 x 686 x 702 mm |
|
Weight |
About 100 kg |
